Features:
When the outdoor temperature is high, a high energy efficiency scroll compressor is used for refrigeration,
which is highly efficient and energy-saving
When the outdoor temperature is low, an energy-saving system is used for refrigeration to reduce air
conditioning energy consumption
High energy efficiency scroll compressor, high efficiency and energy saving
Fully adjustable speed outdoor unit, energy-saving operation and stable system pressure
Large area V-shaped evaporator, high sensible heat ratio design
Intelligent controller, efficient and stable operation of the unit
High-quality components that have been strictly certified
Intelligent controller automatically switches to cold mode, with multiple protection functions to ensure safe a
nd stable operation of the unit
Intelligent control system with fault self-diagnosis and early warning functions
Detachable and transportable structure, 100% full front maintenance
Integrated design, easy to install and maintain
Small footprint
Ultra-large screen full Chinese graphic display
Provide standard RS485 interface, and optional SNMP card for remote monitoring
Intelligent controller, ensuring safe and reliable operation of the unit
Parameters:
| Unit parameter configuration table |
| No |
|
Name |
Parameters |
Brand |
| 1 |
|
model |
Q14 |
Heroth |
| 2 |
Unit performance |
blowing rate (m³/h) |
12900 |
|
| 3 |
Cold volume (kw) |
45.1 |
|
| |
Air-cooling ratio (w / m³ / h) |
3.59 |
|
| 4 |
Input power in nominal refrigeration condition (kw) |
8.8 |
|
| |
Quantity of compressor |
2 |
|
| 5 |
Heat production (electric heating) (kw) |
|
|
| 6 |
Input power in nominal heating condition (kw) |
|
|
| 7 |
External residual pressure (static pressure) (Pa) |
50~350 |
|
| 8 |
Temperature control range is (℃) |
18~31 |
|
| 9 |
source |
380V 50Hz |
|
| 10 |
cryogen |
R22 |
R410a R407c |
| 11 |
Energy saving way |
Electronic expansion valve |
|
| 12 |
energy management |
25.50.75.100 |
|
| 13 |
Electrical heating type |
electrode |
|
| 14 |
Electric heating power (kw) |
15 |
|
| 15 |
Type of humidifier |
The electrode type |
|
| 16 |
Humidification amount (kg) |
13 |
|
| 17 |
Humidifier power (kw) |
9 |
|
| 18 |
Humidifier pipe diameter: (Φ) |
|
|
| 19 |
Humidity control range |
40~75 |
|
| |
|
|
| 20 |
an indoor unit |
Evaporator type |
Copper tube sleeve aluminum fin |
|
| 21 |
air filter |
The initial effect |
|
| 22 |
Indoor fan type |
Low-noise centrifugal fan |
|
| 23 |
Indoor fan power |
|
|
| 24 |
External dimensions (indoor) |
|
|
| 25 |
Unit weight |
|
|
| |
|
|
| 26 |
an outdoor unit |
Condenser type |
Copper tube sleeve aluminum fin |
|
| 27 |
Outdoor fan type |
Low-noise axial flow fan |
|
| 28 |
Power of outdoor fan |
|
|
| 29 |
External dimensions (outdoor) |
|
|
| 30 |
Unit weight |
|
|
| |
|
|
| 31 |
other |
Return to the wind |
Horizontal air supply air, horizontal return air |
|
| 32 |
Indoor and outdoor machine link pipe |
copper pipe |
|
| 33 |
Link form |
weld |
|
| |
quantity |
2 |
|
| |
caliber |
|
|
| 34 |
noise dB(A) |
58 |
|
| 35 |
Remote control system interface |
RS485/RS232 |
|
| 36 |
With the power-off memory function |
Automatic power-on after power outage and reset |
|
| 37 |
With the temperature and humidity early warning function |
The alarm parameters can be set |
|
| |
Unit wiring |
|
|
