Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142
Features Gallery Product Description Request A Quote
Features
Specifications
Part No.: 241123.142
BrandA: Eltek
Model Name: Flatpack2 220V 230/1500 220/0
Voltage (default): 230 VAC / 200 - 240 VAC
Frequency: 50 Hz (adaptive)
Power Maximum: 1200 W (1500 VA) / 2000 VA
Current Maximum: 6.5 ARMS
Current (maximum) Quick Trip (20ms): 32 A (6 X Nominal)
Efficiency: >96%
Highlight:

Eltek Rectiverter Flatpack2 rectifier module

,

220V rectifier module with warranty

,

230/1500 rectifier power supply

Basic Infomation
Place of Origin: CN
Brand Name: Eltek
Certification: CE
Model Number: 241123.142
Payment & Shipping Terms
Packaging Details: cartons
Delivery Time: 8-10 weeks
Payment Terms: L/C,T/T
Supply Ability: 3000 pieces per month
Product Description

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 0
Built on HE technology from the Flatpack2 HE rectifier family the Rectiverter 230/1500 220/1200 provides backed up power for 230 VAC loads with minimum losses and
footprint.
It is a 3 port device capable of charging the 220V battery and simultaneously provides power for the AC and DC loads. During mains outage the Rectiverter feeds AC loads using energy stored in the battery.

Key features

  Unique 3-in-1 operation

  Inverter

  Rectifier

  Power source transfer

  Modular design

  High efficiency

  Global compliance

  Patented technology

  Hot pluggable

  Voltage keying


Parameters :




Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 1


Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 2

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 3

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 4

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 5

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 6

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 7


Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 8Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 9

Eltek Rectiverter Flatpack2 220V 230/1500 220/0 P/N.:241123.142 10
