DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted

1
MOQ
1 USD
Price
DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: DPU60D-N06A1
Input Voltage: 220V
Output Voltage: 48V
Output Type: Multiple
Output Frequency: 60Hz, 50Hz
Output Current: 60A
Power Factor: ≥ 0.95
Output Voltage Range: 42-58 V DC
Highlight:

Wall-mounted Power DPU60D-N06A1

,

Distributed Power DPU60D-N06A1

,

Wall-mounted Power DPU60D

Basic Infomation
Place of Origin: China
Brand Name: Huawei
Certification: CE UL
Model Number: DPU60D-N06A1
Payment & Shipping Terms
Packaging Details: cartons
Delivery Time: 5-10 days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1000 pcs per month
Product Description

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 0

The maximum load power supported by the DC system is the minimum value between the output power of the power module and the output power of the lithium battery module. For example, the parallel output power of 2 power supplies is 5.7kW, the output power of 1 50Ah lithium battery is 3kW, and the maximum load power of the system is 3kW.
When the power supply is paralleled, under the condition of high temperature (ambient temperature > 50°C + solar radiation), the derating factor is 0.95, and the maximum output power of the power supply is 5.7kW (the maximum output of a single power supply is 2.85kW). In other working scenarios, the power is derated according to the module adaptively.
In the scenario of connecting to a lithium battery, the system works in 57V regulated mode, and if you need to customize the output voltage, you need to evaluate and implement it according to the actual load situation

Specification


Model Number

DPU60D-N06A1

Output Type

Multiple

Input Voltage

220V

Output Voltage

48V

Output Frequency

60Hz, 50Hz

Output Current

60A

type

AC-DC

Input

220V Single-phase three-wire input

Input frequency

45-65 Hz

Power factor

≥ 0.95

Output voltage range

42-58 V DC



DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 1

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 2

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 3

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 4

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 5

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 6

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 7

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 8


DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 9

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 10

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 11

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 12

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 13

DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 11


DPU60D-N06A1 Distributed Power 3000W Indoor Or Outdoor Wall Mounted 15

Solutions

We offer all-encompassing solutions tailored for telecommunication companies, both within and beyond China's borders. Our services span from in-depth site surveys to crafting bespoke, professional plans that align precisely with customer demands. Alongside, we provide unwavering technical support and comprehensive maintenance services. With a highly skilled team and a global network of reliable partners, we stand out as a one-stop solution provider.


FAQ :

  1. Q: How do you ensure product quality?
    A: All products undergo rigorous testing before shipment, including simulated usage scenarios, load/full-load testing, and current sharing analysis to validate performance stability.
  2. Q: What's your minimum order quantity (MOQ)?
    A: We have no strict MOQ—even single-unit orders are acceptable. Pricing and lead times may vary based on quantity.
  3. Q: Could you provide a company introduction?
    A: Certainly! I’ll share our detailed company profile document, which covers our history, certifications, and operational capabilities for a comprehensive overview.
  4. Q: What are your company’s core advantages?
    A: Key strengths include robust inventory management for consistent supply, and tailored solutions designed to meet diverse customer requirements flexibly.
  5. Q: Can I request samples with pricing?
    A: Samples are available upon request. Sample pricing aligns with bulk orders, and freight costs are the responsibility of the recipient.
