The eSure™ R48-3500e high-efficiency rectifier is designed to convert standard AC supply voltages into stable nominal -48V DC voltage that is adjustable to application needs. The R48-3500e is a constant power rectifier designed with the latest patented
switchmode technology, using DSP (Digital Signaling Processor) functionality for efficient operation.
For a higher load capacity, rectifiers can be connected in parallel, and intelligent
control can be added with the help of a separate controller.
Features
1.3500 Watt high-efficiency rectifier designed for -48V DC power applications.
2. Optimized depth – reduced footprint allows installation in short-depth racks and cabinets.
3. DSP (Digital Signaling Processor) – means fewer components. optimized operation and active load sharing for increased reliability.
4. Compliant with global standards – delivers quality, performance and reliability no matter what the application or location demands.
5. High efficiency, approaching 97% – reduces power consumption for lower operating costs.
6. Hot pluggable – facilitates future extensions.
Specification
|
Product name
|
R48-3500e
|
|
Working Temperature
|
-40°C~70°C
|
output power
|
3500W
|
|
input voltage range
|
85Vac~300Vac
|
rated input voltage
|
200Vac~250Vac
|
|
incoming current
|
<20A
|
Rated input network frequency
|
50Hz/60Hz
|
|
Output dc voltage range
|
42V~58V
|
Output dc current
|
0A~65.5A
|
Solutions
We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service for Telecommunication Companies in and out of China. We have a competent team and a network of trusted Partners around the world.
FAQ :
1. How do you control the quality?
A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.
2. What is your minimum order quantity?
A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.
3. Can you introduce your company?
A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.
4. What are the advantages of your company?
A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.
5. Can i send samples?Report it to me along with the price?
A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.
6. How do your company deal with the problem on quality?
A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.
7 What about the quality ?
A:100% original with new package. we will test each item before posted to make sure each item with good quality.
8 How many months for guarantee ?
A: 1 year quality guarantee
9 How to deal with any inferior -quality goods ?
A: Goods can be post by with our charge of post fee for any bad quality products within guarantee time.
