Original Eltek Flatpack S 24/1000 HE Rectifier Module 24V 1000W (P/N: 241122.205) - High Efficiency Hot-Swap Telecom Power Supply

The Eltek Flatpack S 24/1000 HE (Part Number: 241122.205) is a state-of-the-art, high-efficiency

switch-mode rectifier module engineered for demanding 24V DC power installations.

With an outstanding power density of 26 W/cu in and a shallow depth of only 217 mm, this compact module delivers

 1000W nominal output power across an input range of 85–305 VAC/DC.

Designed for high availability, the 24/1000 HE features integrated output OR-ing diodes,

active current sharing (±5%), and comprehensive self-protection mechanisms against overvoltage,

short circuits, and extreme thermal conditions. Its plug-and-play architecture allows rapid hot-swap replacement in live

Flatpack S power racks without service interruption, making it the premier choice for telecom and utility maintenance programs worldwide.

Key Feature:

• High Power Density & Compact Depth: 72 x 41.5 x 217 mm housing weighing under 850g, maximizing cabinet capacity.
• 92.5% Peak Energy Efficiency: Reduces thermal dissipation and power consumption across variable load profiles.
• Universal Input Flexibility: Operates seamlessly on 85–305 VAC (45–66 Hz) and DC input voltages up to 300 VDC.
• Built-in Output OR-ing Diode: Guarantees system-level fault isolation and secure N+1 / N+2 redundancy.
• Precise Digital Regulation: Static regulation within ±0.5% and dynamic response < 50ms for 10–90% load steps.
• Status LED Indicators: Tri-color front diagnostics (Normal Green, Warning Yellow, Alarm Red) with CAN bus telemetry.

Applications

• elecom Infrastructure: Spare parts replacement for Eltek Flatpack S 1U/3U rectifiers.
• Railway & Metro Systems: Signaling, trackside interlocking, and train radio power supplies.
• Power Utilities: Substation DC auxiliary systems, switchgear trip coils, and SCADA RTU power.
• Commercial & Marine: Industrial battery chargers and maritime telecom DC systems.

Solutions
We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service

in and out of China. We have a competent team and a network of trusted Partners around the world.

FAQ :
1. How do you control the quality?
A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.

2. What is your minimum order quantity?
A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.

3. Can you introduce your company?
A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.

4. What are the advantages of your company?
A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.

5. Can i send samples?Report it to me along with the price?
A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.

6. How do your company deal with the problem on quality?
A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.
