Home /Products/Telecom Power System/CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301

CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301

5
MOQ
1USD
Price
CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301
Features Gallery Product Description Request A Quote
Features
Specifications
Brand: CE+T
Part Number: T521730301
Dielectric Strength DC/AC: 4300 Vdc
Nominal Output Power (VA) / (W): 3000 VA / 2400 W
DC Voltage: Nominal / Range: 48 VDC / (40-60V)*
Nominal Voltage (AC): 230 V
Voltage Range (AC): 150 - 265 V
Brownout: 1600 W
Highlight:

ECI 48/230 CET Modular Inverters

,

2.4KW CET Modular Inverters

,

Part Nuaber T521730301
Basic Infomation
Place of Origin: CHINA
Brand Name: CE+T
Certification: CE
Model Number: Bravo ECI 48/230 2.4KW
Payment & Shipping Terms
Packaging Details: 48*20*15
Delivery Time: 7-15days
Payment Terms: T/T
Supply Ability: In stock + within one week
Product Description
CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 0
BRAVO is a compact and scalable modular inverter providing a pure sine wave AC supply. In conjunction with a DC Power system, it provides an excellent AC backup solution. It uses the latest inverter technology, providing superior energy efficiency in a compact size.
The ECI technology eliminates all single points of failure with full scalability; up to 32 modules in parallel and high efficiency of up to 96% in AC to AC conversion, and above 93.5% in DC/AC conversion, hence reducing operating costs. We can build the systems up to 2.7 MVA.



Applications

All business critical applications and all types of AC loads. The design is modular and scalable with hot- swappable inverter modules which ensures low Mean Time to Repair (MTTR), reduction in service costs and meets the changing needs for future expansion


Specification



In: DC voltage (input range) 48 Vdc (40-60)
In/Out: AC voltage (input range) 230 Vac (150 – 265)
Output power 3 kVA / 2.4 kW
Efficiency: DC/AC 93.5%
Efficiency: AC/AC 96%
Temperature -20°C to 65°C (de-rating from 40°C)
Dimension 2U x 103 mm x 435 mm
Part number T521730301



CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 1

CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 2CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 3CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 4CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 5

CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 6



Video



CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 7

CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 8
CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 9CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 10

CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 11CE+T Modular Inverters Power Core Bravo ECI 48/230 2.4KW Inverters Part Nuaber T521730301 12​
