Home /Products/DC AC Inverters/Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module

10 pcs
MOQ
1 USD
Price
Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module
Features Gallery Product Description Request A Quote
Features
Specifications
Model No.: SR-1600 PLUS-148
AC Output Voltage: 120VAC
Rating Power: 1600W/1600VA
Output Waveform: Pure Sine Wave
Frequency: 50/60 Hz
DC Input Voltage: 48VDC
AC Input Voltage: 120VAC
Signal Control: LED
Safety & EMC: UL 62368-1 / EN 62368-1
Module Size: .413x3.27x16.14 Inch
Highlight:

Cotek SR-1600 PLUS-148 Rack Inverter

,

48Vdc Input Rack Inverter Module

,

120Vac Output Rack Inverter Module
Basic Infomation
Place of Origin: China
Brand Name: Cotek
Certification: CE UL
Model Number: SR-1600 PLUS-148
Payment & Shipping Terms
Packaging Details: Cartons
Delivery Time: 7-15days
Payment Terms: T/T
Supply Ability: 1000 + / month
Product Description

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 0

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc input 120Vac Output 1600W/1600VA Inverter Module

SR-1600 PLUS Features

Zero transfer time
Standard 19”2U rackmount
Selectable DC Mode / AC Mode (AC Sharing)
High eciency up to 95% at AC Mode
Dual input sources ( AC & DC )
Up to 32 modules can be connected in parallel
Hot swappable module design
Replacable fan module to make maintenance easily
Input Protection: Reverse Polarity / Under Voltage / Over Voltage
Output Protection: Short Circuit / Over Temperature
Unity power factor at AC input
Wide AC&DC input range 150Vac to 265Vac / 36Vdc to 68Vdc
Modbus Protocol Communication

Specification

MODEL SR-1600-124 PLUS, SR-1600-148 PLUS, SR-1600-224 PLUS, SR-1600-248 PLUS
Main Features ◎ New Intelligent Power Conversion Control~ (Software) ◎ Module design hot-swappable, redundancy rack mount inverter ◎ Parallelable module up to 32 pcs ◎ Selectable DC Mode / AC Mode / AC Sharing
AC Output Voltage 100~120VAC; 200~240VAC
Rated Power 1200W/1600VA; 1600W/1600VA; 1200W/1600VA; 1600W/1600VA
Surge Power ─
Output Waveform Pure Sine Wave
Frequency 50/60 Hz
DC Output Voltage ─
DC Output Voltage Range ─
DC Input Voltage 24V / 48V
DC Input Voltage Range 18~34VDC ± 3%; 36~68VDC ± 3%; 18~34VDC ± 3%; 36~68VDC ± 3%
Efficiency AC Mode: 95% DC Mode: 89%; 90%; 90%; 91%
Operating Temperature -25°C ~ 40°C ; Power De-rating from 40°C to 60°C
Storage Temperature -40~70℃
Safety CE / FCC
Dimension (WxHxD) Module: 105x83x410 mm; Shelf: 446x85x509 mm
Weight (Net) Module: 3.8kg; Shelf: 6.5kg
Socket Type Terninal


Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 1

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 2

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 3Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 4

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 5

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 6

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 7

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 8

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 9

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 10

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 11Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 12

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 13

Cotek SR-1600 PLUS-148 Rack Inverter 48Vdc Input 120Vac Output 1600W/1600VA Inverter Module 14
