Custom Made Power Plant FP2 48Vdc 48kw 1000A Indoor Telecom Big Plant Eltek Rectifier Smartpack2 Controller 3 Phase 208V

MOQ

1999 USD

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Brand: Custom Made

Model Number: FP2 48V 48KW 3 Phase 208V

Product Name: 48V Indoor Big System

Input Voltgae: 208Vac

DC Output: 48Vdc

Capacity: 48KW

Current: 1000A

Height: 2000*600*600 Mm

Highlight:

48kw 1000a telecom rectifier systems

48v rectifier module telecom

custom made telecom rectifier 48v

Basic Infomation

Place of Origin: CN

Brand Name: OEM

Certification: CE

Model Number: FP2 48V 48KW 3 phase 208V

Document: datasheet-flatpack2-48v-he-...-1.pdf

Payment & Shipping Terms

Packaging Details: Wooden cartons

Delivery Time: 2-4 weeks

Payment Terms: L/C,D/A,D/P,T/T

Supply Ability: 500 sets / month

Gallery

Custom Made Power Plant FP2 48Vdc 48kw 1000A Indoor Telecom Big Plant Eltek Rectifier Smartpack2 Controller 3 Phase 208V

Product Description

Custom Made FP2 48Vdc 48kw 1000A Indoor Telecom Cabinet Eltek Rectifier Smartpack2 Controller 3 Phase 208V SPD BDLD

Custom Made Power Plant FP2 48Vdc 48kw 1000A Indoor Telecom Big Plant Eltek Rectifier Smartpack2 Controller 3 Phase 208V 0

CET Modular Inverter Module TSI BRAVO 110/230 110Vdc 230Vac 2.5kva 2kw Inverter (P/N.:T321750201)

Description:

TSI Bravo 110/230

Name: Custom Made Power Plant FP2 48Vdc 48kw 1000A Indoor Telecom Big Plant Eltek Rectifier Smartpack2 Controller 3 Phase 208V
Brand: Beijing Ding Ding Future Technology Co.Ltd
SKU: FP2 48V 48KW 3 phase 208V
Price: 1999 USD
Availability: InStock

Bravo110/230

Modular inverter with an extra AC input to reduce energy loss and increase the overall efficiency.

Description:

The FP2 48V 48KW 3 phase 208V Indoor Telecommute Big system designed for Data center for South American market.

The mains input voltage is 3 phase 208V instead of 3 phase 380V.

Max with 16 pcs rectifier slots for Flatpack2 48/3000HE (241119.105) or Flatpack2 48/3000 (241115.903).

Max Current is 1000A. Can be combined to 2000A.

Smartpack2 Controller with 6+6 I/Q monitor. LVLD, LVBD and SPD be optional as custom-made.

Breakers brand as custom- made

Parameters:

Product name

Configuration

48V 48KW 1000A indoor big system

1 48Vdc indoor DC system

2 Dimension: 2000*600*600mm

3 Max 48v 48kw. Max 1000A, 16 pcs slots

4 FP2 48/3000HE ;FP2 48/3000, FP2 48/2000HE for choice

5 Smartpack2 Controller

6 AC input breakers : 2*160A/3P ( custom-made )

7 40KA SPD

8 LVBD load: 2*63A/1P MCB ( custom-made)

9 LVLD load: 2*63A/1P MCB ( custom- made)

10 Fuses load :4*400A ( custom-made)

Custom Made Power Plant FP2 48Vdc 48kw 1000A Indoor Telecom Big Plant Eltek Rectifier Smartpack2 Controller 3 Phase 208V 1
