Home /Products/Telecom Power System/Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100

1 set
MOQ
1￥
Price
Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Rectiverter Systems
AC Output Voltage: 230 VAC / 200 - 240 VAC
DC Output Voltage: 53.5 VDC / 43 - 58 VDC
Input Data: 185 - 275 VAC
Frequency: 47-53 & 57-63 Hz
Power Facotr: > 0.99 At 50% Load Or More / < 3.5%
DC Current: 64 A / 90 A During Overload (15s)
Controller: Smartpack2, Smartpack S & Compack Controllers
Rectifier Module: 242100.100
Rectiverter Module: 242100.102
Highlight:

230V Rectiverter Systems

,

2U 19 inch Rectiverter Systems

,

6KVA Rectiverter Systems
Basic Infomation
Place of Origin: CHINA
Brand Name: ELTEK OR OEM
Model Number: CTOR0201.001
Payment & Shipping Terms
Packaging Details: cartons
Supply Ability: 500 sets per month
Product Description



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 0



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100



The Rectiverter integration/standalone system can be used in applications where a
230/115 VAC backup is needed in parallel with the 48 VDC backup.
The system can be integrated into an Eltek DC system and connected to the same
controller as the 48 VDC system
It can also be used as a standalone system connected to any available 48 VDC
source.
The total output power for both AC and DC output is limited to max 4 kW.
AC and DC output limits can be set according to the attached load, where the
limitation for AC load is set to max 3 kVA.

Key Features:


230Vac input / output
Single input / output
48vdc input / output
4KW AC+DC output
max 3kva AC output
Max 2.4KW DC output
2 pole AC distribution
3 *IEC sockets on front
Bult in transfer technology
150% overload capacity

Product name  Rectiverter systems
Part No. CTOR0201.XXX



Parameters:



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 1



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 2



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 3

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 4Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 5Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 6



(1U Rectiverter avalialbe for your choose )



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 7

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 8Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 9Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 10

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 11

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 12

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 13

Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 14



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 15Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 16



Eltek 6KVA 230V 4.8KW Rectiverter Systems 2U 19 inch Power Shelf Power System CTOR0201.001 242100.100 17
