Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module

5 sets
MOQ
950$ +
Price
Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module
Features Gallery Product Description Chat Now
Features
Specifications
Part No.: CTOS0301.XXX
Power Cpacity: Max 5.4KW As Optional
Rectifier: FlatpackS 48/1800HE
Application: Various
Input Voltgae: 185-240Vac
Output Voltage: 53.5Vdc
Controller: Smartpack S Or Any
Warranty: 1 Year
Package: Cartons
Highlight:

48V 5.4kw Flatpack Power System

,

CTOS0301.1319 flatpack2 48v

,

48V 5.4kw flatpack2 48v

Basic Infomation
Place of Origin: CN
Brand Name: OEM
Certification: CE
Model Number: CTOS0301.1319
Payment & Shipping Terms
Packaging Details: cartons
Delivery Time: 8-10 weeks
Payment Terms: L/C, T/T
Supply Ability: 1500 sets /month
Product Description

Eltek FLATPACK S 1U 3R SYSTEMS 48V 5.4kw Telecom Small Power Systme p/n CTOS0301.1319 with Flatpack S HE 48V/1800WTelecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 0



Eltek FLATPACK S 1U 3R SYSTEMS 48V 5.4kw Telecom Small Power Systme p/n CTOS0301.1319 with Flatpack S HE 48V/1800W

Flatpack S 1U Bulk Feed system is designed for external distributions, due to its many output options it meets the market demand for flexible and expandable DC power solutions.

With its small size, high efficiency, reliability and wide range of communication,

Flatpack S System is the key for future needs. The shallow depth makes the system suitable for most cabinets and thereby excellent as a replacement unit.





Parameters :


Model Controller & 48V rectifier Controller &36V rectifier Controller & 24V rectifiers
Part Number CTOS0301.XXX CTOS0301.XXX CTOSO301.XXX
Input Data
Max Voltage 305Vac
Max Current 9.9A per module 5.9A per module 5.9A per module
Mains configuration 230vAC 3*1 phase or 3 phase
Mains connection 4 mm² terminal blocks, rear connection
Frequency 45 / 65hz
Output Data
Voltage 48Vdc 36Vdc 24 Vdc
Max current 125A 125A 125A
Battery (no breaker portions)
LVBD (80A latched) Optional
Shunt In positive or negative leg
Connection (rear) M6 cable lug
Load ( no breaker position)
Connection (rear) M6 cable lug
Control or Monitoring
Smartpack S 6 input or output connections and Ethernet
Mechanical Data
Dimensions : 19 inch * 1U*250mm
Weight ( including controller ,excluding rectifier ): 4.7kg


                                                           * Flatpack S 1U with 2R avaliable  *

Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 1
Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 2

Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 3Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 4

Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 5Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 6

Telecom Power 1U System 48V 5.4kw Flatpack Power System CTOS0301.1319 with Flatpack S 48/1800HE module 7


Solutions
We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service for Telecommunication Companies in and out of China. We have a competent team and a network of trusted Partners around the world.

FAQ :
1. How do you control the quality?
A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.

2. What is your minimum order quantity?
A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.

3. Can you introduce your company?
A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.

4. What are the advantages of your company?
A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.

5. Can i send samples?Report it to me along with the price?
A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.

6. How do your company deal with the problem on quality?
A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.

7 What about the quality ?
A:100% original with new package. we will test each item before posted to make sure each item with good quality.
8 How many months for guarantee ?
A: 1 year quality guarantee
9 How to deal with any inferior -quality goods ?
A: Goods can be post by with our charge of post fee for any bad quality products within guarantee time.
