The NetSure™ 212 Series of compact -48V power systems is the ideal solution for power plants in the smaller access segment such as street cabinets and other outdoor solutions requiring minimal space with tough environmental conditions, such as very high or very low temperature
The system is designed with up to 6*500W or 1000W NetSure rectifiers and a standard or advanced control unit with TCP/IP to enable remote monitoring and un-attendant operation. The distribution section supports up to 12 circuit breakers ranging from 1-30A or 10* 10-30A fuses and there is a choice of multi-function units providing battery and distribution connections.
Key Features and Specifications:
· Compact and Efficient: The NetSure 212 C23-S1 is designed with a small footprint and high power density, making it suitable for space-constrained environments.
· Hot-Swappable Rectifiers: It allows for the replacement of rectifier modules without interrupting the system's operation, ensuring continuous power delivery.
· Wide Input Voltage Range: The system can operate within a broad input voltage range (90-290VAC) and frequency range (45-65Hz), adapting to varying grid conditions.
· High Efficiency: The system boasts an efficiency exceeding 90%, minimizing energy waste.
· Output Voltage: The output voltage range is typically -42.3V to -57.6V, suitable for powering various telecom equipment.
· Communication Interfaces: It offers various communication interfaces, including RS232 and dry contact, enabling remote monitoring and control.
· Battery Management: The system includes comprehensive battery management features to optimize battery performance and lifespan.
· Modular Design: The NetSure 212 C23-S1 features a modular design, allowing for easy expansion and maintenance.
· Applications: It's commonly used in 4G, FTTx, digital communication, and access equipment.
· Place of Origin: The NetSure 212 C23-S1 is manufactured in Beijing, China.
· Brand: It is an Emerson (now Vertiv) product.
Specification
|
Configuration Model
|
NetSure 212 C23-S1/S2
|
|
Capacity
|
40A
|
|
Controller
|
M225S ( RS232 interface)
|
|
Rectifier
|
20A(R48-1000A)
|
|
AC Distribution
|
S1 input: adopt IEC60320 C14 national standard socket
S2 Input: 3P Barrier Terminals (L+N+PE)
|
|
AC lightning protection
|
Class C (Optional)
|
|
DC Distribution
|
Battery shunt: 1×30A (fuse)
BLVD : 2×20A, 6×10A (fuse)
|
|
DC lightning protection
|
≥10kA (Optional)
|
|
Mechanical parameters
|
483mm(W)×290mm(D)×44mm(H)
|
|
Installation
|
Embedded
|
